3-630T Conventional Welding Rotator

This adjustable welding rotator consists of lead screw adjustable type and bolt adjustable type. It is used for welding of round cylinders. By moving the roller groups according to different diameters of work-piece, the center distance canbe adjusted to suitable for the work-piece with diameters. The adjustable welding rotator consists of powered rotator,idle rotator, driving reducer system and control system etc.
Availability:
Quantity:
Inquire Add to Basket

Product Description

可调

Product Parameter

可调2

The welding rotator is widely used in the assembly, grinding and welding of pipes, boilers and tanks. The welding rotator can be matched with welding manipulator and welding power to form an automatic welding center. Reduce the welding labor of workers, improve production efficiency and welding quality. The conventional welding rotators are consists of power rotator 、passive rotator and electrical control. The wheels of conventional rotators can be adjusted on the base frame to accommodate different vessel diameters.The wheels of conventional rotators distance can be adjusted by screw . If you have special requirements, the power welding rotator and the passive welding rotator can be moved on the track, and the distance between them can be adjusted to weld cylinders of different lengths.

Model
Load & Rotation Capacity
(Ton)
Tanks Diameter Range (mm)
Driven Motor Power (Kw)
Rotation Speed (mm/min)
Wheels Center
Distance
Wheels
Diameter & Width
Roll Dimensions (mm)
C1--C2 (mm)
ΦW*Wr (mm)
Lp * Wp * H
Li * Wi * H
GLHK-3
3
250-1800
2*0.25
100-1000
Speed adjusted by VFD
900--250
200*140
1673*485*385
1260*380*385
GLHK-5
5
250-2300
2*0.37
1100--400
250*140
1894*529*475
1600*436*475
GLHK-10
10
320-2800
2*0.55
1400--450
300*170
2479*605*534
1840*486*534
GLHK-20
20
500-3500
2*1.1
1750--500
350*180
2988*661*649
2450*514*649
GLHK-40
40
600-4200
2*1.5
2000--700
400*200
3489*724*715
2980*600*715
GLHK-60
60
750-4800
2*2.2
2550--760
450*240
4398*861*825
3500*700*825
GLHK-80
80
850-5000
2*3
2500--1000
500*260
4365*900*890
3700*700*890
GLHK-100
100
1000-5500
2*3
2800--1000
500*300
4665*960*955
4000*760*955
GLHK-160
160
1100-6000
2*4
3150--1100
650*250
5528*1052*1140
4550*780*1140
GLHK-250
250
1200-7000
2*5.5
3500--1100
700*280
5168*1115*1245
4930*820*1245
GLHK-500
500
1500--8000
2*7.5
1500--8000
850*350
5824*1331*1565
5500*960*1565
GLHK-630
630
1500--9000
2*11
4400--1200
900*380
6805*1493*1475
6500*1110*1475
