Multi-function 3-Roller Rolling Machine

By setting the length of the straight edge freely, the upper roller presses on the steel plate directly to achieve pre-bending. The rolling technical parameters are numerical controlled, which makes the operation easier and enhances the production efficiency largely.
Availability:
Quantity:
Product Description


Multi-function 3-Roller Rolling Machine


Technical Parameter:

Model

Max thickness (mm)

Max width (mm)

Yield limit  (MPa)

Min bending Dia. (mm)

Rolling speed (m/min)

Main motor power (Kw)

W11SNC-15×2000

15

2000

245

600

4

7.5

W11SNC-20×2000

20

2000

245

800

4

15

W11SNC-20×2500

20

2500

245

800

4

15

W11SNC-20×3000

20

3000

245

800

4

22

W11SNC-25×2500

25

2500

245

900

4

22

W11SNC-25×4000

25

4000

245

1400

4

30

W11SNC-30×2500

30

2500

245

1100

4

30

W11SNC-30×3000

30

3000

245

1200

4

37

W11SNC-30×4000

30

4000

245

1400

4

45

W11SNC-40×2500

40

2500

245

1400

4

55

W11SHNC-40×3000

40

3000

245

1600

4

55

Above are our standard model, it can be designed and manufactured according to customer’s request.


Technical Features:

1. Upper and lower driving, it can finish the end prebending and rolling of metal plate without U-turn.

2. The upper roller is drum shaped roller, there’s adjustable roller supporting device under the lower roller ,which an ensure the accuracy of products.

3. The pressing oil cylinder is positioned on the top place without rod pressing down, which can save energy consumption

4. The material of upper and lower rollers is 42 CrMo, the rollers adopt solid forging with good comprehensive mechanical performance, good core tenacity and high surface hardness, it is suitable for heavy load work with long service life.

5. This machine has an independent operating table to make operation convenient for workers and a safe connecting device, to ensure safety.

6. Economical and applicable, cost-effective, suitable for medium and thick plate rolling system.
